CAT6 UTP Ethernet Flat Patch Cable,RJ45 Unshield

●Small OD and flexibly cable and extreme performance design for Hyper-Scale and Edge Data Center

●100% Cat.6 performance tested in factory
●Farsince Cat6 U/UTP Unshielded Patch Cable is perfect for connecting all kinds of LAN network components, such as PCs, Computer Servers, Printers, Routers, Switch Boxes, Network Media Players, NAS, VOIP Phones, POE devices, etc. Build your home or office network with 1000 Base-T Gigabit Ethernet

●This cable meets or exceeds Category 6 performance in compliance with the TIA/EIA-568-C.2 specifications
●The connectors with gold-plated contacts, molded strain-relief boots, and snagless molds resist corrosion, provide durability, and ensure a secure connection
●Flexible and durable Cat6 U/UTP cable with high bandwidth of up to 500 MHz guarantees high-speed data transfer for server applications, cloud computing, video surveillance, and online high-definition video streaming

SEND INQUIRY

You can make an inquiry about this product.
Your e-mail will not be leaked.

PRODUCT DETAIL
Specification

Features

●Compaliant with the ISO/IEC11801-1 class E and ANSI/TIA 568.2-D Cat.6 channel performance
●Real U/UTP cable structure without any metallic shield design
●Stranded cable for maximun flexibility
●Power over HDBaseT applications up to 100W
●Meets or exceeds TIA/EIA -568B Category 6 and ISO/IEC 11801 Specifications
●Ideal for Data center architectural requirments
●Available with different color of cable
●Available with different length
●ROHS, REACH Compliant

Standard Compliance

●ISO/IEC 11801-1,Class E
●IEC 60603-7-1
●ANSI/TIA-568.2-D
●ANSI/TIA-1096-A
●IEC 60512-99-002
●IEC 60034-2
●IEC 60754-2
●UL444(for UL CM/CMR/CMP PVC jacket material only)

Specification

●Conductor : Bare copper
●Wire Gauge: 24AWG 7/0.20±0.008mm
●Insulation: PE/HDPE
●Insulation color: Blue/White,Blue; Orange/White, Orange;Green/White,Green; Brown/White,Brown
●Shielding: Unshielded
●Jacket Options: PVC/LSZH
●Outer diameter: 5.4±0.2mm
●Connector 1: RJ45 Cat6
●Connector 1: RJ45 Cat6
●Contact: Gold plated, Nickel plated shell
●Testing: Fluke tester
